Question 1

Q1: Do AC300 and B300K support hot swapping?

Accepted Answer

A: Yes. You can easily swap battery packs for continuous power use, and the
system supports up to 4 batteries at once.

Question 2

Q2: Can I connect the B230 battery with AC300?

Accepted Answer

A: No. AC300 is ONLY compatible with B300 and B300K.

Question 3

Q3：How many B300K batteries can l connect with AC300? Can l mix B300K/B300/B300S ?

Accepted Answer

A: The AC300 supports connecting with up to 4 B300 / B300K using the P090A
cable.

Note: The AC300 can mix and match with B300 and B300K. However, it cannot
connect B300, B300K, and B300S batteries simultaneously.

Question 4

Q4: Does AC300 support remote App control?

Accepted Answer

A: Yes. Connect via WiFi or Bluetooth, the BLUETTI App allows you to control the
AC300+B300K remotely, like switching the working modes and upgrading the
firmware.

Question 5

Q5: How to recharge AC300 rapidly?

Accepted Answer

A: Recharge it with the wall outlet and solar panels at the same time, then you
will get a maximum 5,400W input.

Question 6

Q6: Does AC300 have a UPS function?

Accepted Answer

A: Yes. lt supports 4 UPS modes:

1. Standard UPS (Recommended for regions with unstable grid power supply)

2. Time Control UPS (Charge the system during off-peak hours and power your
loads when electricity prices are high)

3. PV Priority UPS (Recommended for regions with sufficient solar energy)

4. Customized UPS (Flexible to tailor the system based on your energy plan)

Question 7

Q7:What is the UPS switching latency?

Accepted Answer

A: 20ms.

Question 8

Q8: What can I do with the touchscreen?

Accepted Answer

A: For details, please refer to the AC300 touchscreen guide below:

AC300 | Touchscreen Guide.
[https://www.youtube.com/watch?v=IqNXq9arIQQ&list=PL7XvQcJvK2jlGYvYi_nmjVrM10WUcd1jb&index=4]

Question 9

Q9: What cables are included in the package?

Accepted Answer

A: Standard Packaging

AC300

1. 10A AC Charging Cable: 59in / 150cm

2. DC Input Cable: 59in / 150cm

3. Car Charging Cable: 20in / 50cm

B300K

P090D Battery Expansion Cable: 31.5in / 80cm

Optional

1. Lead-acid Battery Charging Cable: 19.4in / 50cm

2. 12V / 30A RV Cable: 31.5in / 80cm + 50cm

3. P150D to P090D Cable: 31.5in / 80cm

4. Cigarette Lighter to DC5521 Cable (24V): 38in / 72cm

Question 10

Q10: Can the AC300 be used alone?

Accepted Answer

A: No, the AC300 has no built-in battery. Please use it with the B300 or B300K
battery.

Question 11

Q11: Where can I buy the solar panel extension cable? Will it affect the solar input power?

Accepted Answer

A: You can purchase it on BLUETTI Store
[https://www.bluettipower.com.au/products/bluetti-solar-extension-cable] .
Please note that the longer the cable, the greater the power loss in the solar
input.

Question 12

Q12: How to install the AC300+ B300K system for home backup?

Accepted Answer

A: For details, please refer to "How to build a partial backup system with
AC300+B300K
[https://cdn.shopify.com/s/files/1/0557/7159/4918/files/How_to_build_a_partialhome_backup_system_with_AC300_B300.pdf?v=1727073552]".

Question 13

Q13: How long will the combo power the devices?

Accepted Answer

A: Runtime = Capacity × DoD × η ÷ (load power + self-consumption)

Note:

1) DoD refers to the Depth of Discharge, η is the local inverter efficiency.
DoD=90%, η=90%.

2) The above data is for reference ONLY.

Question 14

Q14: What is the self-consumption of the AC300?

Accepted Answer

A: When the AC300 is on standby, it's 20W with AC and DC off, and 50W with AC
and DC on.

Question 15

Q15: How long does it take to fully charge the AC300+B300K?

Accepted Answer

A: Charging time (estimated) = (total capacity / charging power) + trickle
charge time

The trickle charge time for BLUETTI power station is typically 0.5-1 hours.

Question 16

Q16: What is the Max. charging power of AC300?

Accepted Answer

A: 1. 3,000W Max. with 1* B300K (PV+AC);

2. 5,400W Max. with 2* B300K or more (PV+AC).

Question 17

Q17: How many solar panels can I connect with AC300+B300K? How to connect them?

Accepted Answer

A: AC300 support dual MPPT, each MPPT of AC300 accepts 1-6* PV120 / 1-5* PV200 /
1-3* PV350 / 1-3* PV420 solar panels.

Series connecting is highly commended for the best efficiency and durability.

Question 18

Q18: Can the solar input current exceed 15A?

Accepted Answer

A: Yes, but the extra current will be wasted.

Question 19

Q19: Can the solar input power exceed 2,400W?

Accepted Answer

A: Yes, however, please ensure the total voltage does not exceed 150V.

Question 20

Q20:Can l use third party solar panels to charge AC300?

Accepted Answer

A: Yes, as soon as the solar panels meet the following conditions:

1) Total Voc: 12V-150V

2) Total power: 2,400W Max.

3) With MC4 connectors

Question 21

Q21:Can I charge the system by connecting B300K to solar panels or an adapter?

Accepted Answer

A: No.

Question 22

Q22:How to maintain and store the AC300+B300K?

Accepted Answer

A: 1. When the SoC drops to 5%, please charge the product immediately.

2. Before storing the product, charge it to 60% SOC to keep it in optimal
condition. In addition, power off the unit and disconnect all electrical
connections from it.

3. Store the product in a cool and dry place, keeping it away from flammable or
combustible materials and gases.

4. The power station can be safely stored within a temperature range of -20°C to
45°C ( -4°F to 113°F). However, if the storage duration exceeds one month, it's
recommended to maintain an ideal storage temperature of around 30°C (86°F).

5. Fully cycle the product every 3 months to maintain the battery's health.

Question 23

Q23:Can I connect different types of solar panels to the AC300?

Accepted Answer

A: Yes. AC300 features dual MPPT charge controllers, please ensure the solar
panels in each controller are consistent.

Question 24

Q24:What to consider when recharging the AC300+B300K from a generator?

Accepted Answer

A: 1. The generator's output voltage, and frequency should fall within the range
of AC300.

2. If your generator's output power can't meet the AC300's input specs, you can
easily adjust the Maximum Grid Input Current via the app. This ensures your
generator can still efficiently charge the AC300.

3. Use a generator with sine wave output.

Question 25

Q25:Can I charge the AC300 from solar panels, a car, and AC power simultaneously?

Accepted Answer

A: Yes. However, the Max. input is limited at 5,400W.

Question 26

Q26:Can I charge the AC300 from a 12V/24V DC/DC charger, MPPT controller, or other solar controller?

Accepted Answer

A: Yes. However, the Max. charging power is limited to 100W (12V) or 200W (24V).
Please set the "DC input source" to "Others".

Question 27

Q27:ls AC300 waterproof?

Accepted Answer

A: No, please use and store it in a cool and dry place.

Capacity	5,529.6Wh	5,529.6Wh
Type	LiFePO₄	LiFePO₄
Life Cycles	4,000+ Cycles	4,000+ Cycles
AC Outlets	6×220V-240V/13A, 3000W In Total	3 x 240V/10A Outlets 2 x 240V/15A 1 x 240V/32A 5,000W In Total
Surge Power	6,000W	10,000W
AC Input	3000W Max.	5000W Max.
Solar Input	2400W Max.,12-150VDC,12A	3,000W Max., VOC 12-150VDC, 15A
Weight	21.6 kg(AC300)/29.5kg(B300K)	30 kg(AC500)/29.5kg(B300K)
Dimensions (L x W x D)	523235.80cm(AC300)/52.532.720.9cm(B300K)	523235.80cm(AC500)/52.532.720.9cm(B300K)
Warranty	4 Years	4 Years
