Question 1

Q1: Why do I need Charger 1? How does it compare to the cigarette lighter port?

Accepted Answer

A: A standard cigarette lighter port in a 12V vehicle outputs around 100W, while
a 24V vehicle outputs about 200W. Charger 1, on the other hand, delivers up to
560W of power while your vehicle is running, allowing you to charge your power
station much faster than with a regular cigarette lighter.

Question 2

Q2: What vehicles are compatible with Charger 1?

Accepted Answer

A: Charger 1 can be used with any vehicle with a 12V or 24V starter battery,
including RVs, vans, and trucks.

Question 3

Q3: Can I use Charger 1 on a hybrid or EV?

Accepted Answer

A: Charger 1 can be used with hybrid vehicles, as long as the vehicle has an
alternator and a starter battery. However, it can’t be used with EVs because
their charging and battery management systems operate differently from those in
traditional gasoline-powered cars.

Question 4

Q4: Will Charger 1 drain my car battery? Do I need to turn it off each time?

Accepted Answer

A: Charger 1 features an intelligent algorithm that monitors the connected
battery. It automatically stops drawing power from your car's battery 3-6
seconds after the engine is off, preventing battery drain. While the engine is
running, Charger 1 remains active and can be controlled through the BLUETTI app,
allowing you to start and stop charging your power station as needed.

Question 5

Q5: Will Charger 1 harm my car battery or affect its lifespan?

Accepted Answer

A: No, Charger 1 monitors your car battery’s voltage and adjusts its output
accordingly. If the battery voltage is low, Charger 1 reduces power output; if
the voltage is high, it increases output. If the battery drops below
12.0V/26.0V, Charger 1 triggers undervoltage protection and stops charging. With
proper maintenance, your car battery will last as long as intended even when
using Charger 1.

Question 6

Q6: Does using Charger 1 affect my car's fuel consumption?

Accepted Answer

A: Charger 1 uses excess power from the alternator to charge your power
stations, with minimal impact on fuel consumption.

Question 7

Q7: Is it safe to install Charger 1 by myself since it requires a connection to the car battery?

Accepted Answer

A: Yes, Charger 1 comes with a 6AWG cable and a circuit breaker. By flipping the
switch on the circuit breaker, you can safely disconnect the cable, preventing
shocks or electrical sparks during installation. If you're unsure, it's always
best to seek help from a professional.

Question 8

Q8: What tools or what preparations do I need to install Charger 1?

Accepted Answer

A: You’ll need a wrench to work on the car battery's screw nuts and install the
cable wire lugs. If you plan to mount Charger 1 on the side of your trunk/boot,
a drill and a board are required. Just be sure to leave enough space for
ventilation. Charger 1 also comes with a small hex screwdriver for connecting
the cables.

Question 9

Q9: It is necessary to install or hang Charger 1 exactly as instructed?

Accepted Answer

A: No, you can install Charger 1 in a position that suits you, as long as you
ensure there is enough space for the fan to ventilate properly.

Question 10

Q10: Can I install it even if I have little knowledge about cars/vehicles?

Accepted Answer

A: Absolutely! While working under the hood may seem intimidating at first, the
installation process is easier than you might think. We provide a detailed
instructional video to guide you through each step. The most challenging part is
usually routing the cable from the engine compartment to the trunk, but with our
guidance, you'll have it done in no time!

Question 11

Q11: Why does the optional input cable come with a 60A circuit breaker？

Accepted Answer

A: The 60A circuit breaker is included to protect your vehicle, Charger 1, and
power station. In the unlikely event of a high surge current, the circuit
breaker will automatically trip, disconnecting Charger 1 from the vehicle
battery and safeguarding all connected components. You can easily reset the
circuit breaker by flipping the handle back to restore the connection. It's a
user-friendly and reliable solution for protecting your equipment.

Question 12

Q12: It it necessary to purchase the optional input cable? What if I already have my own cables?

Accepted Answer

A: The optional input cables are not mandatory; you can certainly use your own
cables if you prefer a DIY approach. However, we recommend using 6 AWG
cables for optimal safety. Our package also includes tube terminals and OT
terminals, making it easy for you to complete your installation with your own
cables.

Question 13

Q13: Why isn’t my Charger 1 charging my power station when my car is running?

Accepted Answer

A: If your Charger 1 isn't charging, follow these steps to troubleshoot:

1. Turn off your engine and ensure all cables are properly connected.
Double-check that the positive and negative cables are correctly attached and
securely tightened.

2. Restart your engine and observe the indicator light on Charger 1. Refer to
the instruction manual to understand what the light indicates and whether
Charger 1 is functioning correctly.

3. Let your engine run for a while to allow the car battery to charge fully.
Charger 1 is designed not to operate when the car battery is low.

If these steps don’t resolve the issue, please contact our support team for
further assistance.

Question 14

Q14: Which power stations are compatible with Charger 1? Can it charge third-party power stations?

Accepted Answer

A: Charger 1 is compatible with all BLUETTI power stations, as well as
third-party power stations or solar generators that use MC4 connectors for solar
charging. Please note that in rare cases, third-party power stations may
experience an unstable charging rate.

Question 15

Q15: Do I need to adjust settings on Charger 1 for different power stations?

Accepted Answer

A: Yes, once Charger 1 is activated, you'll need to adjust the "Charging
Voltage" to match the specifications of your power station. This can be easily
done through the BLUETTI app. The default output voltage of Charger 1 is 27V,
which is ideal for smaller power stations like the AC2A, EB3A, EB55, EB70S,
AC60, and AC50B. For larger power stations, such as the AC70, AC180, AC180T,
AC200MAX, AC200L, AC240, AC300, and AC500, a higher output voltage setting is
recommended.

Question 16

Q16: Can I save a specific charging setting for one power station?

Accepted Answer

A: Yes, you can save a specific charging setting as the default for one power
station. However, remember to adjust the charging voltage if you use Charger 1
with a different power station.

Question 17

Q17: Why isn’t my BLUETTI Power Station charging at the claimed 560W?

Accepted Answer

A: First, ensure that the power station connected to Charger 1 is capable of
handling a 560W DC/solar charging input.

Next, check the output voltage of Charger 1. The default setting is 27V, but to
achieve 560W charging, you need to set Charger 1 to a 56V output.

Question 18

Q18: Will Charger 1 work if my car gets really hot in the sun?

Accepted Answer

A: Yes, Charger 1 is designed to operate in temperatures ranging from -4°F to
140°F /-20°C to 60°C. If it gets too hot, the built-in fan will automatically
turn on to cool the device and prevent overheating.

Question 19

Q19: How much power does Charger 1 actually draw?

Accepted Answer

A: Charger 1 draws up to 50A from 12V vehicles and up to 25A from 24V vehicles.

Question 20

Q20: Why is Charger 1’s 560W output six times faster than normal car charging?

Accepted Answer

A: Typically, car charging through a 12V cigarette lighter port can reach up to
100W, but it often drops to around 80W. In contrast, Charger 1 delivers a
consistent 560W output, making it about six times faster than charging through a
cigarette lighter port, based on lab testing results.

Question 21

Q21: What is the operating battery voltage for Charger 1?

Accepted Answer

A: For 12V vehicles:
12.5V: Power on
12.6V: Start charging
12.0V: Stop charging
For 24V vehicles:
25.0V: Power on
25.2V: Start charging
26.0V: Stop charging

Question 22

Q22: Can I connect two Charger 1 units in parallel to charge my power station?

Accepted Answer

A: No
